Specification

This is the canonical technical specification for Infrastructure Mapper. It captures what the system must do and how it must behave, such that the project could be re-implemented from scratch in another language and arrive at a homologous outcome.

It is updated whenever functionality is added, removed, or changed.

1. Purpose and scope

Infrastructure Mapper is a relational geospatial schema for capturing physical infrastructure (buildings, fences, roads, water, electricity, gates, poles, points of interest, vegetation, monitoring stations, culinary facilities, and land-use areas) plus their conditions over time.

The schema is the deliverable. It is intended to be loaded into:

  • A PostgreSQL/PostGIS database (the canonical, server-side store).
  • A GeoPackage file (the offline, field-portable snapshot), opened in QGIS desktop or in QField / Mergin Maps for capture.

2. Architecture

sql/                                 baseline schema (immutable once committed)
├── extensions.sql                   enable PostGIS
├── 0-meta.sql                       schema_migrations + current_schema_version
├── 1-infrastructure.sql … 13-roads.sql   capture domains
├── fixtures.sql                     lookup data
└── migrations/
    ├── pg/
    │   ├── UNRELEASED.sql           editable; consolidated into vX.Y.Z.sql at release
    │   └── vX.Y.Z.sql               frozen released migrations (PostgreSQL syntax)
    └── gpkg/
        ├── UNRELEASED.sql
        └── vX.Y.Z.sql               frozen released migrations (SQLite syntax)

scripts/
├── build_gpkg.sh                    PG → ogr2ogr → GPKG pipeline
├── migrate_pg.sh                    Apply pending PG migrations to a target DB
├── migrate_gpkg.py                  Apply pending GPKG migrations to a target file
├── generate_schema_docs.py          Refresh "Schema Reference" sections in docs/data-model/
├── release.sh                       Cut a release: rename UNRELEASED → vX.Y.Z, bump VERSION
└── check_schema_immutability.sh     Pre-commit / CI gate

.github/workflows/
├── ci.yml                           Pre-commit suite + tests on every PR
├── SchemaImmutability.yml           Pre-commit hook mirror for PRs and tag pushes
├── Release.yml                      On tag push, build and publish release artifacts
└── Docs.yml                         On push to main, rebuild and publish docs

VERSION                              Single line of plain semver, e.g. "0.1.0"
gpkg/KartozaInfrastructureMapper.gpkg  Latest local build of the GeoPackage

3. Versioning

3.1 Version stamp

  • VERSION at repo root contains a single semver string (MAJOR.MINOR.PATCH).
  • Every PG and GPKG database produced by the build process must include the schema_migrations table (defined in sql/0-meta.sql) with at least one row recording the baseline version.
  • The current_schema_version view must return exactly one row representing the highest applied version.

3.2 Bump rule

Per the project's commit convention:

  • Bugfix-only changes → patch bump.
  • New features → minor bump.
  • Breaking schema changes → major bump.

4. Schema immutability

4.1 Baseline files

Files under sql/ at the top level (extensions.sql, 0-meta.sql, <n>-<domain>.sql, fixtures.sql) form the baseline. Once committed, each is frozen. The pre-commit hook and the SchemaImmutability GitHub Action reject any in-place modification.

New top-level files for new capture domains are permitted (e.g. a future sql/14-solar.sql). They become immutable from the moment they are first committed.

4.2 Released migrations

Files matching sql/migrations/{pg,gpkg}/vX.Y.Z.sql are frozen on commit by the same gate.

4.3 UNRELEASED files

sql/migrations/pg/UNRELEASED.sql and sql/migrations/gpkg/UNRELEASED.sql are the only freely-editable schema files. They are renamed to vX.Y.Z.sql at release time.

4.4 Issue-NNN annotation

Every block appended to either UNRELEASED.sql must be preceded by an annotation line of the form:

-- Issue #NNN: short description

referencing the GitHub issue that tracks the change. The hook rejects any top-level DDL/DML keyword (CREATE, ALTER, DROP, INSERT, …) that does not have a preceding -- Issue #NNN: line in the file.

5. Release process

5.1 Local release script

scripts/release.sh runs in two modes because main is protected (direct pushes are rejected — releases must land via PR).

Mode A — --bump <major|minor|patch> --commit [--empty]:

  1. Refuses to run unless on a clean main that matches origin/main.
  2. Reads VERSION, computes the next version X.Y.Z.
  3. Requires that at least one of the two UNRELEASED.sql files contain a -- Issue # block (override with --empty).
  4. Creates a release branch release/vX.Y.Z.
  5. git mv both UNRELEASED.sql → vX.Y.Z.sql.
  6. Recreates empty UNRELEASED.sql files (header preserved).
  7. Writes new version into VERSION.
  8. Regenerates per-component schema reference docs under docs/data-model/.
  9. Commits everything as Release vX.Y.Z, pushes the branch, opens a PR via gh pr create.

Mode B — --tag (no --bump):

  1. Refuses to run unless on main at origin/main.
  2. Reads VERSION (now X.Y.Z from the merged PR).
  3. Creates an annotated tag vX.Y.Z at main HEAD.
  4. Pushes the tag, which triggers Release.yml.

5.2 Release pipeline

The Release GitHub Action triggers on v* tag push. It publishes the following artifacts to the release:

Artifact Description
pg-schema-vX.Y.Z.sql pg_dump --schema-only from a fresh reference PG
pg-fixtures-vX.Y.Z.sql pg_dump --data-only of lookup tables
KartozaInfrastructureMapper-vX.Y.Z.gpkg Blank GeoPackage built via ogr2ogr
pg-migrations-vX.Y.Z.tar.gz Every sql/migrations/pg/v*.sql + migrate_pg.sh
gpkg-migrations-vX.Y.Z.tar.gz Every sql/migrations/gpkg/v*.sql + migrate_gpkg.py
RELEASE_NOTES.md Generated from filenames between previous and current tags

The migration tarballs ship the full history; the runners skip migrations already recorded in the target's schema_migrations table, so one tarball serves any prior version.

6. Migration application

6.1 Runners

  • scripts/migrate_pg.sh <dbname> for PostgreSQL.
  • scripts/migrate_gpkg.py <file.gpkg> for GeoPackage.

6.2 Strict sequential semantics

Both runners:

  1. Read the target's current_schema_version.
  2. List all locally-available vX.Y.Z.sql files sorted in semver order.
  3. Apply every file whose semver is greater than the target's current version, in order, each in its own transaction.
  4. Record successful application in schema_migrations with checksum and applied_by.
  5. Are idempotent: re-running on an up-to-date DB is a no-op.
  6. Support --dry-run (print plan only) and --target vX.Y.Z (stop at).

If the local file set has a gap (e.g. v1.1.sql and v1.3.sql present, v1.2.sql missing), the runner reports which file is missing rather than silently skipping.

7. Coordinate reference systems

7.1 Schema baseline

Every spatial column in the baseline declares EPSG:4326.

7.2 Build-time reprojection

scripts/build_gpkg.sh --crs EPSG:NNNN reprojects every spatial column during build. The reprojection runs as ALTER TABLE … ALTER COLUMN geometry TYPE GEOMETRY(<type>, <srid>) USING ST_Transform(geometry, <srid>) on the throwaway PG, so the declared type and the stored geometry stay consistent.

7.3 Geographic-CRS warning

When --crs is omitted or set to EPSG:4326, the build script emits a warning explaining that geographic CRSes are only accurate to ~2 m.

7.4 Runtime reprojection

migrate_pg.sh --crs EPSG:NNNN may reproject after applying migrations. For GPKG, in-place reprojection requires SpatiaLite extensions or an external ogr2ogr pass; the runner refuses with a clear message rather than silently producing wrong geometries.

7.5 PG-GPKG CRS coupling

The system assumes a paired prod PG and prod GPKG share the same CRS at sync time. CRS mismatch is not silently reconciled.

8. Field sync model

The GPKG is a versioned snapshot. The sync workflow (GPKG → PG) is not yet implemented but the schema supports it: every table has a uuid (stable across both stores) and a last_update timestamp. A future scripts/sync_gpkg_to_pg.py will merge by UUID, with the conflict policy to be decided.

9. Generated documentation

scripts/generate_schema_docs.py regenerates the "Schema Reference" section inside each docs/data-model/NN-<domain>.md. The section is delimited by:

<!-- SCHEMA-REFERENCE-START - auto-generated, do not edit by hand -->
…
<!-- SCHEMA-REFERENCE-END -->

Content outside those markers is hand-curated narrative and must not be touched by the generator.

The generated content reflects the materialised current state of the schema — baseline plus every applied PG migration — and includes per table: description, columns (name, type, nullability, default, description), and constraints (PK, UNIQUE, FK, CHECK).

10. Built-in metadata

sql/0-meta.sql defines:

  • schema_migrations(version, major, minor, patch, applied_at, applied_by, checksum, is_baseline, notes) — append-only history of applied versions; is_baseline = TRUE distinguishes the initial build from applied migrations.
  • current_schema_version view — single-row introspection helper.

These must be present in any environment claiming to be an Infrastructure Mapper database.

11. Documentation site

The user-facing documentation is published as a mkdocs-material site at https://timlinux.github.io/InfrastructureMapper/. It is built and deployed by the Docs.yml GitHub workflow on every push to main.

The site sources live under docs/ and use the Kartoza design system (design.md) for typography, palette, and component styling. Per-component schema reference blocks are regenerated by scripts/generate_schema_docs.py as part of the deploy workflow, so the docs site is never stale relative to main.
